Dynamic Air Vent

Dynamic Air Vent has a revolutionary diaphragm that maximizes system protection with controlled air intake and discharge. This air vent is normally closed when the line is not operating preventing debris and contaminants from entering the pipeline.

Why Dynamic Air Vent

  • Rolling diaphragm principle allows air to be discharged in a controlled and gradual manner preventing slam and surges.
  • Reacts very quickly to vacuum surges by intaking large amounts of air - three times more air than other vents.
  • Air vent is normally closed when the line is not operating preventing debris and contaminants from entering the pipeline.
  • Light-weight and small for easy installation with simple and reliable operation.
  • Built-in outlet connection for surplus water drainage.
  • Corrosion-resistant composite materials.

Product Advantages

  • Air vent is normally closed when the line is not operating preventing debris and contaminants from entering the pipeline.
  • Light-weight and small for easy installation with simple and reliable operation.
  • Built-in outlet connection for surplus water drainage.
  • Corrosion-resistant composite materials.
  • Installation on irrigation systems with any diameter pipeline when the slope is greater than 2 - 3%
  • Installation on irrigation systems with 8” or great diameter pipelines
  • For discharge of air at pump and filtration stations, along mains and at the end of mainlines
  • At high points in the pipe network or upstream of manifolds

Applications

  • Installation on irrigation systems with any diameter pipeline when the slope is greater than 2 – 3%
  • Installation on irrigation systems with 8” or great diameter pipelines
  • For discharge of air at pump and filtration stations, along mains and at the end of mainlines
  • At high points in the pipe network or upstream of manifolds

Specifications

Specifications

  • Maximum operating pressure: 150 psi
  • Maximum working temperature: 140° F
  • Available size: 2” a 3″ NPT Male Threaded

Materials

  • Body: Reinforced Nylon
  • Drainage Elbow: Polypropylene
  • Rolling Seal: EPDM Rubber
  • O-Ring: BUNA-N

Downloads

PRODUCT SHEET

PRODUCT SHEET
